PRIM SWITCH PSUPPLY 2.24W 24VDC
RISH FLEX - E 1512A is a Industrial, DIN Rail Power Supplies manufactured by Rishabh Instruments. PRIM SWITCH PSUPPLY 2.24W 24VDC. Key specifications: operating temperature -30°C ~ 70°C (With Derating), current - output (max) 1.25A, size / dimension 2.44" L x 0.71" W x 3.54" H (62.0mm x 18.0mm x 90.0mm), number of outputs 1.
In Stock: 5
| Attribute | Value |
|---|---|
| Product Status | Active |
| Input Type | AC or DC |
| Number of Outputs | 1 |
| AC Voltage - Input | 85 ~ 264 VAC |
| DC Voltage - Input (Min) | 120V |
| DC Voltage - Input (Max) | 370V |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output (Max) | 1.25A |
| Power (Watts) | - |
| Voltage - Isolation | 3 kV |
| Applications | ITE (Commercial) |
| Efficiency | 87% |
| Operating Temperature | -30°C ~ 70°C (With Derating) |
| Features | DC Input Capable |
| Size / Dimension | 2.44" L x 0.71" W x 3.54" H (62.0mm x 18.0mm x 90.0mm) |
| Approval Agency | - |
| Standard Number | 60950-1 |
Submit your RFQ for RISH FLEX - E 1512A and get a quote within 24 hours.
