RES CHAS MNT 500 OHM 5% 200W
PF2272-500RJ1 is a Chassis Mount Resistors manufactured by Riedon. RES CHAS MNT 500 OHM 5% 200W. Key specifications: mounting feature Flanges, operating temperature -55°C ~ 155°C, package / case SOT-227-4, size / dimension 1.496" L x 0.984" W (38.00mm x 25.00mm).
In Stock: 3,204
| Attribute | Value |
|---|---|
| Product Status | Active |
| Resistance | 500 Ohms |
| Tolerance | ±5% |
| Power (Watts) | 200W |
| Composition | Thick Film |
| Temperature Coefficient | ±100ppm/°C |
| Operating Temperature | -55°C ~ 155°C |
| Features | Current Sense, Flame Proof, Moisture Resistant, Pulse Withstanding, Safety |
| Coating, Housing Type | Aluminum Oxide |
| Mounting Feature | Flanges |
| Size / Dimension | 1.496" L x 0.984" W (38.00mm x 25.00mm) |
| Height - Seated (Max) | 0.484" (12.30mm) |
| Lead Style | M4 Threaded |
| Package / Case | SOT-227-4 |
| Failure Rate | - |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| TGHLV500RJE | Ohmite | RES CHAS MNT 500 OHM 5% 200W | 100% | View |
| TGHMV500RJE | Ohmite | 500 OHM 300 WATT SOT227 5% TF | 74% | View |
| TGHHV500RJE | Ohmite | RES CHAS MNT 500 OHM 5% 120W | 67% | View |
| TGHDV470RJE | Ohmite | 100W MINI SOT227 470 OHMS 5% | 51% | View |
| LPSA800H4700JB | Vishay Sfernice | LPSA 800 H 470U 5% BO15 | 51% | View |
| LPS1100H4700JB | Vishay Sfernice | RES CHAS MNT 470 OHM 5% 1100W | 51% | View |
Submit your RFQ for PF2272-500RJ1 and get a quote within 24 hours.
