FIXED IND 3.3UH 2.5A 87 MOHM SMD
BMRA000404203R3MA1 is a Fixed Inductors manufactured by Pulse Electronics Power. FIXED IND 3.3UH 2.5A 87 MOHM SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 125°C, package / case Nonstandard, current rating (amps) 2.5 A.
In Stock: 1,019
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Molded |
| Material - Core | - |
| Inductance | 3.3 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 2.5 A |
| Current - Saturation (Isat) | 4A |
| Shielding | Shielded |
| DC Resistance (DCR) | 87mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -55°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.161" L x 0.181" W (4.10mm x 4.60mm) |
| Height - Seated (Max) | 0.079" (2.00mm) |
Submit your RFQ for BMRA000404203R3MA1 and get a quote within 24 hours.
