SPEAKER 8OHM 700MW TOP PORT 94DB
AS01508AO-WP-R is a Speakers manufactured by PUI Audio, Inc.. SPEAKER 8OHM 700MW TOP PORT 94DB. Key specifications: size / dimension 0.591" L x 0.433" W (15.00mm x 11.00mm), termination Solder Pads, ingress protection IP65 - Dust Tight, Water Resistant, power - max 1 W.
In Stock: 7,698
| Attribute | Value |
|---|---|
| Product Status | Active |
| Technology | Magnetic |
| Type | General Purpose |
| Frequency Range | 500 Hz ~ 14 kHz |
| Frequency - Self Resonant | 500Hz |
| Impedance | 8 Ohms |
| Efficiency - dBA | 94.00 |
| Efficiency - Testing | 700mW/100mm |
| Efficiency - Type | Sound Pressure Level (SPL) |
| Power - Rated | 700 mW |
| Power - Max | 1 W |
| Port Location | Top |
| Shape | Rectangular |
| Material - Cone | Polyester, Polyethylene Terephthalate (PET) |
| Material - Magnet | Nd-Fe-B |
| Ingress Protection | IP65 - Dust Tight, Water Resistant |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.591" L x 0.433" W (15.00mm x 11.00mm) |
| Height - Seated (Max) | 0.126" (3.20mm) |
Submit your RFQ for AS01508AO-WP-R and get a quote within 24 hours.
