IC OFFLINE SW FLYBACK 10CSDIP
TOP253MG is a PMIC - AC DC Converters, Offline Switchers manufactured by Power Integrations. IC OFFLINE SW FLYBACK 10CSDIP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 150°C (TJ), package / case 10-SDIP (0.300", 7.62mm), 9 Leads, power (watts) 25 W.
In Stock: 1,949
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Topology | Flyback |
| Voltage - Start Up | - |
| Voltage - Supply (Vcc/Vdd) | - |
| Duty Cycle | 78% |
| Frequency - Switching | 66kHz |
| Power (Watts) | 25 W |
| Fault Protection | Current Limiting, Over Temperature, Over Voltage |
| Control Features | - |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Package / Case | 10-SDIP (0.300", 7.62mm), 9 Leads |
| Supplier Device Package | SDIP-10C |
| Mounting Type | Through Hole |
TOP253MG is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| TOP254PN | Power Integrations | IC OFFLINE SWITCH FLYBACK 8DIP | 97% | View |
| TOP254EG | Power Integrations | IC OFFLINE SWITCH FLYBACK 7ESIP | 75% | View |
| TOP261EG | Power Integrations | IC OFFLINE SWITCH FLYBACK 7ESIP | 70% | View |
| TOP267EG | Power Integrations | IC OFFLINE SWITCH FLYBACK 7ESIP | 70% | View |
| TOP258EG | Power Integrations | IC OFFLINE SWITCH FLYBACK 7ESIP | 70% | View |
| TOP258EN | Power Integrations | IC OFFLINE SWITCH FLYBACK 7ESIP | 70% | View |
Submit your RFQ for TOP253MG and get a quote within 24 hours.
