CONN D-SUB HD PLUG 78P SLDR CUP
DD78M200EX-14 is a D-Sub Connectors manufactured by PEI-Genesis. CONN D-SUB HD PLUG 78P SLDR CUP. Key specifications: mounting type Free Hanging (In-Line), current rating (amps) 5A, termination Solder Cup, ingress protection IP65/IP67 - Dust Tight, Water Resistant, Waterproof.
In Stock: 1
| Attribute | Value |
|---|---|
| Product Status | Active |
| Connector Style | D-Sub, High Density |
| Connector Type | Plug, Male Pins |
| Number of Positions | 78 |
| Number of Rows | 4 |
| Mounting Type | Free Hanging (In-Line) |
| Shell Size, Connector Layout | 5 (DD, D) High Density |
| Contact Type | Signal |
| Flange Feature | Cable Side, Male Jackscrew (4-40) |
| Termination | Solder Cup |
| Primary Material | - |
| Shell Material, Finish | Steel, Tin Plated |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Ingress Protection | IP65/IP67 - Dust Tight, Water Resistant, Waterproof |
| Material Flammability Rating | UL94 V-0 |
| Current Rating (Amps) | 5A |
| Backset Spacing | - |
| Features | - |
Submit your RFQ for DD78M200EX-14 and get a quote within 24 hours.
