Panasonic Electronic Components
CAP FILM 20UF 10% 500VDC RADIAL
EZP-E50206LTA is a Film Capacitors manufactured by Panasonic Electronic Components. CAP FILM 20UF 10% 500VDC RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage rating - dc 500V, package / case Radial.
In Stock: 154
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 20 µF |
| Tolerance | ±10% |
| Voltage Rating - AC | - |
| Voltage Rating - DC | 500V |
| Dielectric Material | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 11 mOhms |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 1.634" L x 0.787" W (41.50mm x 20.00mm) |
| Height - Seated (Max) | 1.673" (42.50mm) |
| Termination | PC Pins |
| Lead Spacing | 1.476" (37.50mm) |
| Applications | DC Link, DC Filtering |
| Ratings | - |
| Features | Low ESR |
Submit your RFQ for EZP-E50206LTA and get a quote within 24 hours.
