Panasonic Electronic Components
CAP ALUM 47UF 20% 100V RADIAL
EEU-FS2A470L is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 47UF 20% 100V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 100 V, package / case Radial, Can.
In Stock: 2,934
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 47 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 8000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 413 mA @ 120 Hz |
| Ripple Current @ High Frequency | 590 mA @ 100 kHz |
| Impedance | 112 mOhms |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.650" (16.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ESY476M100AH1AA | KEMET | CAP ALUM 47UF 20% 100V RADIAL | 83% | View |
| ESH476M100AH2AA | KEMET | CAP ALUM 47UF 20% 100V RADIAL | 76% | View |
| 420HXW47MEFR10X35 | Rubycon | CAP ALUM 47UF 20% 420V RADIAL | 74% | View |
| URZ2C470MHD1TN | Nichicon | CAP ALUM 47UF 20% 160V RADIAL | 73% | View |
| EKWA451ELL470MJ45S | United Chemi-Con | RADIAL ALUMINUM ELECTROLYTIC CAP | 70% | View |
| URZ2E470MHD1TN | Nichicon | CAP ALUM 47UF 20% 250V RADIAL | 66% | View |
