Panasonic Electronic Components
CAP ALUM 33UF 20% 100V RADIAL
EEU-FS2A330 is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 33UF 20% 100V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 100 V, package / case Radial, Can.
In Stock: 180
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 33 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 6000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 269.5 mA @ 120 Hz |
| Ripple Current @ High Frequency | 490 mA @ 100 kHz |
| Impedance | 160 mOhms |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.512" (13.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEU-FC2A330LJ | Panasonic Electronic Components | CAP ALUM 33UF 20% 100V RADIAL | 78% | View |
| ESH336M100AH1EA | KEMET | CAP ALUM RAD 105C | 77% | View |
| EKWA401ELL330MJ30S | United Chemi-Con | RADIAL ALUMINUM ELECTROLYTIC CAP | 71% | View |
| UBT2C330MPD1TD | Nichicon | CAP ALUM 33UF 20% 160V RADIAL | 59% | View |
| B43851A5336M000 | EPCOS - TDK Electronics | CAP ALUM 33UF 20% 450V RADIAL | 53% | View |
| 80ZLH33MEFCTA6.3X11 | Rubycon | CAP ALUM 33UF 20% 80V RADIAL | 51% | View |
