Panasonic Electronic Components
CAP ALUM 820UF 20% 50V RADIAL
EEU-FR1H821L is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 820UF 20% 50V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 50 V, package / case Radial, Can.
In Stock: 4,887
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 820 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.453 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.27 A @ 100 kHz |
| Impedance | 14 mOhms |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EKZE500ELL821ML20S | United Chemi-Con | CAP ALUM 820UF 20% 50V RADIAL | 82% | View |
| 160TXW820MEFR18X50 | Rubycon | CAP ALUM 820UF 20% 160V RADIAL | 76% | View |
| LGG2Z821MELZ40 | Nichicon | CAP ALUM 820UF 20% 180V SNAP | 72% | View |
| 200MXC820KEFH25X45 | Rubycon | CAP ALUM 820UF 10% 200V SNAP | 56% | View |
| 860160578030 | Würth Elektronik | CAP ALUM 820UF 20% 35V RADIAL | 55% | View |
| EKZE250ETD821MJ25S | United Chemi-Con | CAP ALUM 820UF 20% 25V RADIAL | 54% | View |
