Panasonic Electronic Components
CAP ALUM 820UF 20% 50V RADIAL
EEU-FC1H821 is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 820UF 20% 50V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 50 V, package / case Radial, Can.
In Stock: 6,756
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 820 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 1.815 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.42 A @ 100 kHz |
| Impedance | 42 mOhms |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.709" Dia (18.00mm) |
| Height - Seated (Max) | 0.787" (20.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL213661821E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 820UF 20% 50V RADIAL | 84% | View |
| ELXV500ELL821ML25S | United Chemi-Con | CAP ALUM 820UF 20% 50V RADIAL | 82% | View |
| EEU-FC1V821LB | Panasonic Electronic Components | CAP ALUM 820UF 20% 35V RADIAL | 77% | View |
| B41689K7827Q001 | EPCOS - TDK Electronics | CAP ALUM 820UF 40V AXIAL | 69% | View |
| 757D827M025DG3D | Vishay Sprague | CAP ALUM 820UF 20% 25V RADIAL | 64% | View |
| 672D827H015DS5C | Vishay Sprague | CAP ALUM 820UF 15V RADIAL | 56% | View |
Submit your RFQ for EEU-FC1H821 and get a quote within 24 hours.
