Panasonic Electronic Components
CAP ALUM 100UF 20% 160V RADIAL
EEU-EE2C101S is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 100UF 20% 160V RADIAL. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 160 V, package / case Radial, Can.
In Stock: 7,928
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 100 µF |
| Tolerance | ±20% |
| Voltage - Rated | 160 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 680 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.7 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 0.866" (22.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EKXN351ELL101MK35S | Chemi-Con | CAP ALUM 350V POLAR | 76% | View |
| RXQ101M2GBK-1832S | Surge | CAP ALUM 400V POLAR | 76% | View |
| 400LXW100MEFR12.5X50 | Rubycon | CAP ALUM 100UF 20% 400V RADIAL | 74% | View |
| RLD101M2WBK-1840S | Surge | CAP ALUM 450V POLAR | 71% | View |
| SL107M100HGHRR | NextGen Components | CAP ALUM 100UF 20% 100V 10K HRS | 70% | View |
| REA1450101M400B | KYOCERA AVX | CAP ALUM 400V POLAR | 65% | View |
Submit your RFQ for EEU-EE2C101S and get a quote within 24 hours.
