Panasonic Electronic Components
CAP ALUM 33UF 20% 250V RADIAL
EEU-EB2E330 is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 33UF 20% 250V RADIAL. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 250 V, package / case Radial, Can.
In Stock: 7,797
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 33 µF |
| Tolerance | ±20% |
| Voltage - Rated | 250 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 308 mA @ 120 Hz |
| Ripple Current @ High Frequency | 560 mA @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 0.866" (22.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UCY2E330MPD | Nichicon | CAP ALUM 33UF 20% 250V RADIAL | 98% | View |
| UCS2D330MPD1TD | Nichicon | CAP ALUM 33UF 20% 200V RADIAL | 88% | View |
| PW2E330MSD1020 | Chinsan (Elite) | ALUMINUM ELECTROLYTIC CAPACITORS | 87% | View |
| UCS2E330MHD | Nichicon | CAP ALUM 33UF 20% 250V RADIAL | 85% | View |
| 250WXA33MEFC16X16 | Rubycon | CAP ALUM 33UF 20% 250V RADIAL | 83% | View |
| 420LXW33MEFR12.5X20 | Rubycon | CAP ALUM 33UF 20% 420V RADIAL | 75% | View |
Submit your RFQ for EEU-EB2E330 and get a quote within 24 hours.
