Panasonic Electronic Components
CAP ALUM 68UF 20% 160V RADIAL
EEU-EB2C680 is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 68UF 20% 160V RADIAL. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 160 V, package / case Radial, Can.
In Stock: 6,692
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 68 µF |
| Tolerance | ±20% |
| Voltage - Rated | 160 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 412.5 mA @ 120 Hz |
| Ripple Current @ High Frequency | 750 mA @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 1.063" (27.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MALIEYH07LU268X02K | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 68UF 20% SNAP | 100% | View |
| 200BXW68MEFR10X25 | Rubycon | CAP ALUM 68UF 20% 200V RADIAL | 84% | View |
| 686KFM250MRU | Cornell Dubilier / Illinois Capacitor | CAP ALUM 68UF 20% 250V RADIAL | 79% | View |
| 686LMB400M2BC | Cornell Dubilier / Illinois Capacitor | CAP ALUM 68UF 20% 400V SNAP | 72% | View |
| 500VXG68MEFCSN25X25 | Rubycon | CAP ALUM 68UF 20% 500V SNAP | 59% | View |
| MAL214839689E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 68UF 20% 100V RADIAL | 55% | View |
Submit your RFQ for EEU-EB2C680 and get a quote within 24 hours.
