Panasonic Electronic Components
CAP ALUM 390UF 20% 450V SNAP
EET-UQ2W391KA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 390UF 20% 450V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 85°C, voltage - rated 450 V, package / case Radial, Can - Snap-In.
In Stock: 7,889
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 390 µF |
| Tolerance | ±20% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | 510mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -25°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.24 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.136 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.575" (40.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
EET-UQ2W391KA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LDM2G391MERAGA | Nichicon | CAP ALUM 390UF 20% 400V RADIAL | 95% | View |
| 500MXG390MEFCSN35X55 | Rubycon | CAP ALUM 390UF 20% 500V SNAP | 93% | View |
| ALC70E391DD450 | KEMET | CAP ALUM 390UF 20% 450V SNAP | 87% | View |
| ELXS421VSN391MA35S | United Chemi-Con | CAP ALUM 390UF 20% 420V SNAP | 85% | View |
| B43252A9397M | EPCOS - TDK Electronics | CAP ALUM 390UF 20% 400V SNAP | 83% | View |
| EKMH401VSN391MA40S | United Chemi-Con | CAP ALUM 390UF 20% 400V SNAP | 76% | View |
Submit your RFQ for EET-UQ2W391KA and get a quote within 24 hours.
