Panasonic Electronic Components
CAP ALUM 470UF 20% 350V SNAP
EET-UQ2V471LA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 470UF 20% 350V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 85°C, voltage - rated 350 V, package / case Radial, Can - Snap-In.
In Stock: 9,232
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 470 µF |
| Tolerance | ±20% |
| Voltage - Rated | 350 V |
| ESR (Equivalent Series Resistance) | 423mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -25°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.4 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.36 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.181" (30.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
EET-UQ2V471LA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ALA7DD471DD450 | KEMET | CAP ALUM 470UF 20% 450V SNAP | 82% | View |
| EKMM451VNN471MA50W | United Chemi-Con | CAP ALUM 470UF 20% 450V SNAP | 80% | View |
| 420MXK470MEFCSN35X30 | Rubycon | CAP ALUM 470UF 20% 420V SNAP | 79% | View |
| ELXM251VSN471MR30S | United Chemi-Con | CAP ALUM 470UF 20% 250V SNAP | 69% | View |
| LGU2P471MELA | Nichicon | CAP ALUM 470UF 20% 220V SNAP | 63% | View |
| EKMH201VSN471MR25S | United Chemi-Con | CAP ALUM 470UF 20% 200V SNAP | 62% | View |
Submit your RFQ for EET-UQ2V471LA and get a quote within 24 hours.
