Panasonic Electronic Components
CAP ALUM 470UF 20% 350V SNAP
EET-UQ2V471CA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 470UF 20% 350V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 85°C, voltage - rated 350 V, package / case Radial, Can - Snap-In.
In Stock: 2,513
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 470 µF |
| Tolerance | ±20% |
| Voltage - Rated | 350 V |
| ESR (Equivalent Series Resistance) | 423mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -25°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.4 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.36 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.984" Dia (25.00mm) |
| Height - Seated (Max) | 1.772" (45.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
EET-UQ2V471CA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL229967471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 450V SNAP | 90% | View |
| MAL205358471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 385V RADIAL | 89% | View |
| MAL209327471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 450V SNAP | 89% | View |
| ALC40A471DF400 | KEMET | CAP ALUM 470UF 20% 400V SNAP | 88% | View |
| PL2G471MND3043Y | Chinsan (Elite) | ALUMINUM ELECTROLYTIC CAPACITORS | 86% | View |
| MAL225772471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 200V SNAP | 73% | View |
Submit your RFQ for EET-UQ2V471CA and get a quote within 24 hours.
