Panasonic Electronic Components
CAP ALUM POLY HYB 150UF 50V SMD
EEH-ZU1H151V is a Aluminum - Polymer Capacitors manufactured by Panasonic Electronic Components. CAP ALUM POLY HYB 150UF 50V SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 135°C, voltage - rated 50 V, package / case Radial, Can - SMD.
In Stock: 4,981
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Hybrid |
| Capacitance | 150 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | 12mOhm |
| Lifetime @ Temp. | 4000 Hrs @ 135°C |
| Operating Temperature | -55°C ~ 135°C |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Features | - |
| Ripple Current @ Low Frequency | 690 mA @ 100 Hz |
| Ripple Current @ High Frequency | 4.6 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.516" (13.10mm) |
| Surface Mount Land Size | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEH-ZU1H151P | Panasonic Electronic Components | CAP ALUM POLY HYB 150UF 50V SMD | 100% | View |
| GWC1H151MCO1GS | Nichicon | 50V 150F HYBRID POLYMER CHIP CHI | 96% | View |
| EEH-ZU1J151P | Panasonic Electronic Components | CAP ALUM POLY HYB 150UF 63V SMD | 87% | View |
| A785MW157M1JLAS013 | KEMET | CAP ALUM HYB 150UF 20% 63V SMD | 84% | View |
| GWC1J151MNU1GS | Nichicon | 63V 150F HYBRID POLYMER CHIP CHI | 84% | View |
| 35PHV150M8X10.5 | Rubycon | CAP ALUM POLY HYB 150UF 35V SMD | 52% | View |
Submit your RFQ for EEH-ZU1H151V and get a quote within 24 hours.
