Panasonic Electronic Components
CAP ALUM POLY 120UF 20% 50V T/H
EEH-AZT1H121B is a Aluminum - Polymer Capacitors manufactured by Panasonic Electronic Components. CAP ALUM POLY 120UF 20% 50V T/H. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 125°C, voltage - rated 50 V, package / case Radial, Can.
In Stock: 1,859
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Hybrid |
| Capacitance | 120 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | 23mOhm |
| Lifetime @ Temp. | 4000 Hrs @ 125°C |
| Operating Temperature | -55°C ~ 125°C |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Features | - |
| Ripple Current @ Low Frequency | 435 mA @ 100 Hz |
| Ripple Current @ High Frequency | 2.9 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.413" (10.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| A7C3MS127M1JAAS019 | KEMET | CAP HYBRID ALUM RAD 120UF 63V | 91% | View |
| 63PZK120M10X11 | Rubycon | CAP ALUM HYBRID TH 63V 120UF 20% | 87% | View |
| A7C5MN127M1HAAS028 | KEMET | CAP ALU HYBRID RADL 120UF 50V | 86% | View |
| A7C5MN127M1HBAS028 | KEMET | CAP ALU HYBRID RADL 120UF 50V | 86% | View |
| EEH-AZSJ121UB | Panasonic Electronic Components | CAP ALUM POLY HYB 120UF 63V T/H | 84% | View |
| EEH-AZC1H121B | Panasonic Electronic Components | CAP ALUM POLY 120UF 20% 50V T/H | 72% | View |
Submit your RFQ for EEH-AZT1H121B and get a quote within 24 hours.
