Panasonic Electronic Components
CAP ALUM POLY 330UF 20% 35V T/H
EEH-AZS1V331B is a Aluminum - Polymer Capacitors manufactured by Panasonic Electronic Components. CAP ALUM POLY 330UF 20% 35V T/H. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 125°C, voltage - rated 35 V, package / case Radial, Can.
In Stock: 2,000
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Hybrid |
| Capacitance | 330 µF |
| Tolerance | ±20% |
| Voltage - Rated | 35 V |
| ESR (Equivalent Series Resistance) | 14mOhm |
| Lifetime @ Temp. | 4000 Hrs @ 125°C |
| Operating Temperature | -55°C ~ 125°C |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Features | - |
| Ripple Current @ Low Frequency | 525 mA @ 100 Hz |
| Ripple Current @ High Frequency | 3.5 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.500" (12.70mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEH-AZT1E331B | Panasonic Electronic Components | CAP ALUM POLY 330UF 20% 25V T/H | 90% | View |
| A7C3MN337M1VAAS020 | KEMET | CAP HYBRID ALUM RAD 330UF 35V | 89% | View |
| HHSE250ELL331MJC5S | United Chemi-Con | CAP ALUM HYBRID 330UF 20% 25V TH | 86% | View |
| 35PZK470M10X11 | Rubycon | CAP ALUM HYBRID TH 35V 470UF 20% | 85% | View |
| EEH-AZKV391UB | Panasonic Electronic Components | CAP ALUM POLY 390UF 20% 35V T/H | 83% | View |
| EEH-AZKE331UB | Panasonic Electronic Components | CAP ALUM POLY 330UF 20% 25V T/H | 63% | View |
Submit your RFQ for EEH-AZS1V331B and get a quote within 24 hours.
