Panasonic Electronic Components
CAP ALUM POLY 56UF 20% 63V T/H
EEH-AZF1J560 is a Aluminum - Polymer Capacitors manufactured by Panasonic Electronic Components. CAP ALUM POLY 56UF 20% 63V T/H. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 150°C, voltage - rated 63 V, package / case Radial, Can.
In Stock: 6,452
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Type | Hybrid |
| Capacitance | 56 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | 30mOhm |
| Lifetime @ Temp. | 1000 Hrs @ 150°C |
| Operating Temperature | -55°C ~ 150°C |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Features | - |
| Ripple Current @ Low Frequency | 126 mA @ 100 Hz |
| Ripple Current @ High Frequency | 840 mA @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.413" (10.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
EEH-AZF1J560 is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEH-AZF1J560B | Panasonic Electronic Components | CAP ALUM POLY 56UF 20% 63V T/H | 100% | View |
| EEH-AZF1H560B | Panasonic Electronic Components | CAP ALUM POLY 56UF 20% 50V T/H | 84% | View |
| EEH-AZF1H560 | Panasonic Electronic Components | CAP ALUM POLY 56UF 20% 50V T/H | 84% | View |
| EEH-AZF1H101B | Panasonic Electronic Components | CAP ALUM POLY 100UF 20% 50V T/H | 68% | View |
| EEH-AZF1J330B | Panasonic Electronic Components | CAP ALUM POLY 33UF 20% 63V T/H | 58% | View |
| EEH-AZF1V101B | Panasonic Electronic Components | CAP ALUM POLY 100UF 20% 35V T/H | 56% | View |
Submit your RFQ for EEH-AZF1J560 and get a quote within 24 hours.
