Panasonic Electronic Components
CAP ALUM 33UF 20% 25V RADIAL
EEA-GA1E330B is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 33UF 20% 25V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 25 V, package / case Radial, Can.
In Stock: 14,486
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 33 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 75 mA @ 120 Hz |
| Ripple Current @ High Frequency | 116.2 mA @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.248" Dia (6.30mm) |
| Height - Seated (Max) | 0.276" (7.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| RXW330M1EBK-0511S | Surge | CAP ALUM 25V POLAR | 89% | View |
| UPW1E330MDD | Nichicon | CAP ALUM 33UF 20% 25V RADIAL | 82% | View |
| RXW330M1VBK-0511S | Surge | CAP ALUM 35V POLAR | 79% | View |
| RXW330M1CBK-0511S | Surge | CAP ALUM 16V POLAR | 76% | View |
| RJA330M1HBK-0511S | Surge | CAP ALUM 50V POLAR | 71% | View |
| MAL216051339E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 33UF 20% 50V RADIAL | 56% | View |
Submit your RFQ for EEA-GA1E330B and get a quote within 24 hours.
