Panasonic Electronic Components
CAP FILM 0.15UF 20% 275VAC RAD
ECQ-U2A154MG is a Film Capacitors manufactured by Panasonic Electronic Components. CAP FILM 0.15UF 20% 275VAC RAD. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 100°C, voltage rating - ac 275V, package / case Radial.
In Stock: 1,170
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 0.15 µF |
| Tolerance | ±20% |
| Voltage Rating - AC | 275V |
| Voltage Rating - DC | - |
| Dielectric Material | Polyester, Metallized |
| ESR (Equivalent Series Resistance) | - |
| Operating Temperature | -40°C ~ 100°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.689" L x 0.315" W (17.50mm x 8.00mm) |
| Height - Seated (Max) | 0.669" (17.00mm) |
| Termination | PC Pins |
| Lead Spacing | 0.591" (15.00mm) |
| Applications | EMI, RFI Suppression |
| Ratings | X2 |
| Features | - |
ECQ-U2A154MG is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MKP1840415404 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 0.15UF 5% RADIAL | 100% | View |
| PHE850EF6150MF11R06L2 | KEMET | CAP FILM 0.15UF 20% 1.25KVDC RAD | 98% | View |
| QXL2E154KTPT | Nichicon | CAP FILM 0.15UF 10% 250VAC RAD | 98% | View |
| F339X241530KFM2B0 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 0.15UF 10% 630VDC RAD | 98% | View |
| B32023B3154K000 | EPCOS - TDK Electronics | CAP FILM 0.15UF 10% 300VAC RAD | 98% | View |
| ECW-F2154JAQ | Panasonic Electronic Components | CAP FILM 0.15UF 5% 250VDC RADIAL | 86% | View |
