Panasonic Electronic Components
CAP FILM 0.18UF 2% 50VDC RADIAL
ECQ-P1H184GZW is a Film Capacitors manufactured by Panasonic Electronic Components. CAP FILM 0.18UF 2% 50VDC RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage rating - dc 50V, package / case Radial.
In Stock: 4,534
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 0.18 µF |
| Tolerance | ±2% |
| Voltage Rating - AC | - |
| Voltage Rating - DC | 50V |
| Dielectric Material | Polypropylene (PP) |
| ESR (Equivalent Series Resistance) | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.787" L x 0.354" W (20.00mm x 9.00mm) |
| Height - Seated (Max) | 0.827" (21.00mm) |
| Termination | PC Pins |
| Lead Spacing | 0.394" (10.00mm) |
| Applications | High Frequency, Switching |
| Ratings | - |
| Features | - |
ECQ-P1H184GZW is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ECQ-B1H184JF | Panasonic Electronic Components | CAP FILM 0.18UF 5% 50VDC RADIAL | 100% | View |
| BFC236512184 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 0.18UF 5% 63VDC RADIAL | 96% | View |
| BFC246707184 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 0.18UF 5% 100VDC RADIAL | 88% | View |
| 150184K100CB | Cornell Dubilier Electronics (CDE) | CAP FILM 0.18UF 10% 100VDC AXIAL | 88% | View |
| BFC233914184 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 0.18UF 10% 630VDC RAD | 71% | View |
| BFC236865184 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 0.18UF 10% 630VDC RAD | 71% | View |
