Panasonic Electronic Components
CAP FILM 3.9UF 5% 100VDC RADIAL
ECQ-E1395JFA is a Film Capacitors manufactured by Panasonic Electronic Components. CAP FILM 3.9UF 5% 100VDC RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage rating - dc 100V, package / case Radial.
In Stock: 3,597
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 3.9 µF |
| Tolerance | ±5% |
| Voltage Rating - AC | - |
| Voltage Rating - DC | 100V |
| Dielectric Material | Polyester, Metallized |
| ESR (Equivalent Series Resistance) | - |
| Operating Temperature | -40°C ~ 105°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 1.024" L x 0.276" W (26.00mm x 7.00mm) |
| Height - Seated (Max) | - |
| Termination | PC Pins |
| Lead Spacing | - |
| Applications | General Purpose |
| Ratings | - |
| Features | - |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ECW-F2395JA | Panasonic Electronic Components | CAP FILM 3.9UF 5% 250VDC RADIAL | 84% | View |
| BFC246816395 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 3.9UF 10% 250VDC RADIAL | 84% | View |
| MKP385539040JKM2T0 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 3.9UF 5% 400VDC RADIAL | 75% | View |
| ECW-FG70395K | Panasonic Electronic Components | CAP FILM 3.3UF 700VDC RADIAL | 71% | View |
| MKP385539100JYI2T0 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 3.9UF 5% 1KVDC RADIAL | 71% | View |
| MKP385E53963JPM4T0 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 3.9UF 5% 630VDC RAD | 71% | View |
