Panasonic Electronic Components
CAP ALUM 820UF 20% 100V SNAP
ECO-S2AA821AA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 820UF 20% 100V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 100 V, package / case Radial, Can - Snap-In.
In Stock: 4,346
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 820 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | 202mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.4 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.1 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.787" Dia (20.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
ECO-S2AA821AA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LGU1K821MELZ | Nichicon | CAP ALUM 820UF 20% 80V SNAP | 76% | View |
| UBY1K821MHL | Nichicon | CAP ALUM 820UF 20% 80V RADIAL | 67% | View |
| 50ZLH820MEFCGC16X20 | Rubycon | CAP ALUM 820UF 20% 50V RADIAL | 66% | View |
| LGG2P821MELB30 | Nichicon | CAP ALUM 820UF 20% 220V SNAP | 66% | View |
| 860160475026 | Würth Elektronik | CAP ALUM 820UF 20% 25V RADIAL | 65% | View |
| 220MXC820MEFCSN35X30 | Rubycon | CAP ALUM 820UF 20% 220V SNAP | 64% | View |
Submit your RFQ for ECO-S2AA821AA and get a quote within 24 hours.
