Panasonic Electronic Components
CAP ALUM 4700UF 20% 35V SNAP
ECO-S1VP472DL is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 4700UF 20% 35V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 35 V, package / case Radial, Can - Snap-In.
In Stock: 1,623
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 4700 µF |
| Tolerance | ±20% |
| Voltage - Rated | 35 V |
| ESR (Equivalent Series Resistance) | 88mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.3 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 0.787" (20.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
ECO-S1VP472DL is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEU-FC1A472 | Panasonic Electronic Components | CAP ALUM 4700UF 20% 10V RADIAL | 75% | View |
| UPA1C472MHD1TN | Nichicon | CAP ALUM 4700UF 20% 16V RADIAL | 71% | View |
| MAL205851472E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 4700UF 20% 50V SNAP | 65% | View |
| EEU-TA1C472 | Panasonic Electronic Components | CAP ALUM 4700UF 20% 16V RADIAL | 60% | View |
| 478TMA016M | Cornell Dubilier / Illinois Capacitor | CAP ALUM 4700UF 20% 16V AXIAL | 58% | View |
| 478LMB080M2EF | Cornell Dubilier / Illinois Capacitor | CAP ALUM 4700UF 20% 80V SNAP | 50% | View |
Submit your RFQ for ECO-S1VP472DL and get a quote within 24 hours.
