Panasonic Electronic Components
CAP ALUM 6800UF 20% 25V SNAP
ECO-S1EA682AA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 6800UF 20% 25V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 25 V, package / case Radial, Can - Snap-In.
In Stock: 2,914
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 6800 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | 73mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.4 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.76 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.787" Dia (20.00mm) |
| Height - Seated (Max) | 1.654" (42.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
ECO-S1EA682AA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 35MXG6800MEFCSN22X40 | Rubycon | CAP ALUM 6800UF 20% 35V SNAP | 90% | View |
| 35MXR6800M25X35 | Rubycon | CAP ALUM 6800UF 20% 35V SNAP | 88% | View |
| 25VXG6800MEFC25X30 | Rubycon | CAP ALUM 6800UF 20% 25V SNAP | 88% | View |
| 35VXG6800MEFC30X30 | Rubycon | CAP ALUM 6800UF 20% 35V SNAP | 87% | View |
| EKYB6R3ELL682MK30S | United Chemi-Con | CAP ALUM 6800UF 20% 6.3V RADIAL | 78% | View |
| 16YXF6800MEFCGC18X35.5 | Rubycon | CAP ALUM 6800UF 20% 16V RADIAL | 74% | View |
Submit your RFQ for ECO-S1EA682AA and get a quote within 24 hours.
