Panasonic Electronic Components
CAP ALUM 5600UF 20% 25V SNAP
ECO-S1EA562AA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 5600UF 20% 25V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 25 V, package / case Radial, Can - Snap-In.
In Stock: 7,821
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 5600 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | 89mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.2 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.53 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.787" Dia (20.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
ECO-S1EA562AA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 10ZLH5600MEFC12.5X35 | Rubycon | CAP ALUM 5600UF 20% 10V RADIAL | 100% | View |
| LGU1H562MELZ | Nichicon | CAP ALUM 5600UF 20% 50V SNAP | 100% | View |
| THAS562M035AD0C | Cornell Dubilier Electronics (CDE) | CAP ALUM 5600UF 20% 35V FLATPACK | 100% | View |
| EKY-100ELL562ML25S | United Chemi-Con | CAP ALUM 5600UF 20% 10V RADIAL | 100% | View |
| B41890A4568M | EPCOS - TDK Electronics | CAP ALUM 5600UF 20% 16V RADIAL | 100% | View |
| EKMH350VSN562MQ30U | United Chemi-Con | CAP ALUM 5600UF 20% 35V SNAP | 100% | View |
Submit your RFQ for ECO-S1EA562AA and get a quote within 24 hours.
