Panasonic Electronic Components
CAP FILM 6UF 5% 220VAC RADIAL
ECH-A22605JX is a Film Capacitors manufactured by Panasonic Electronic Components. CAP FILM 6UF 5% 220VAC RADIAL. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 70°C, voltage rating - ac 220V, package / case Radial.
In Stock: 3,748
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 6 µF |
| Tolerance | ±5% |
| Voltage Rating - AC | 220V |
| Voltage Rating - DC | - |
| Dielectric Material | Polyester, Polyethylene, Metallized |
| ESR (Equivalent Series Resistance) | - |
| Operating Temperature | -25°C ~ 70°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 1.457" L x 0.768" W (37.00mm x 19.50mm) |
| Height - Seated (Max) | 1.240" (31.50mm) |
| Termination | PC Pins |
| Lead Spacing | 1.280" (32.50mm) |
| Applications | Motor Run |
| Ratings | - |
| Features | - |
ECH-A22605JX is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| C4AQOLU4600M19J | KEMET | CAP FILM 6UF 5% 900VDC RADIAL | 100% | View |
| MKP1848560454K2 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 6UF 5% 450VDC RADIAL | 100% | View |
| B32774X9605K000 | EPCOS - TDK Electronics | FILM CAP MKP DC FILTERING - 900V | 100% | View |
| MKP1847560274K2 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 6UF 5% 275VAC RADIAL | 96% | View |
| MKP1847560354P2 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 6UF 5% 350VAC RADIAL | 92% | View |
| PSB1854600KRST | Nichicon | FILM CAP BOXED RADIAL | 85% | View |
Submit your RFQ for ECH-A22605JX and get a quote within 24 hours.
