Panasonic Electronic Components
CAP ALUM 560UF 20% 400V SNAP
ECE-T2GP561EA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 560UF 20% 400V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 85°C, voltage - rated 400 V, package / case Radial, Can - Snap-In - 4 Lead.
In Stock: 7,394
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | 326mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 85°C |
| Operating Temperature | -25°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.72 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.808 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.886" (22.50mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.969" (50.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In - 4 Lead |
ECE-T2GP561EA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 450USC560MEFC35X50 | Rubycon | CAP ALUM 560UF 20% 450V SNAP | 94% | View |
| B43642B9567M062 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 400V SNAP | 94% | View |
| 400HXG560MEFC35X45 | Rubycon | CAP ALUM 560UF 20% 400V SNAP | 93% | View |
| 450VXH560MEFC35X45 | Rubycon | CAP ALUM 560UF 20% 450V SNAP | 85% | View |
| ESMH251VNN561MQ40W | United Chemi-Con | CAP ALUM 560UF 20% 250V SNAP | 75% | View |
| B41789A8567Q001 | EPCOS - TDK Electronics | CAP ALUM 560UF 63V RADIAL | 66% | View |
