Panasonic Electronic Components
CAP ALUM 6800UF 20% 100V SNAP
ECE-T2AP682EA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 6800UF 20% 100V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 100 V, package / case Radial, Can - Snap-In - 4 Lead.
In Stock: 1,290
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 6800 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | 49mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 6.6 A @ 120 Hz |
| Ripple Current @ High Frequency | 7.59 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.886" (22.50mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.969" (50.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In - 4 Lead |
ECE-T2AP682EA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ESMH800VSN682MA40S | United Chemi-Con | CAP ALUM 6800UF 20% 80V SNAP | 82% | View |
| B41605B688M9 | EPCOS - TDK Electronics | CAP ALUM 6800UF 20% 55V RADIAL | 67% | View |
| ESMH630VNN682MA30U | United Chemi-Con | CAP ALUM 6800UF 20% 63V SNAP | 65% | View |
| EKMH630VNN682MR50W | United Chemi-Con | CAP ALUM 6800UF 20% 63V SNAP | 59% | View |
| EKMH630VSN682MR50S | United Chemi-Con | CAP ALUM 6800UF 20% 63V SNAP | 59% | View |
| 63MXG6800MEFCSN25X45 | Rubycon | CAP ALUM 6800UF 20% 63V SNAP | 58% | View |
