Panasonic Electronic Components
CAP ALUM 22000UF 20% 50V SNAP
ECE-T1HP223EA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 22000UF 20% 50V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 50 V, package / case Radial, Can - Snap-In - 4 Lead.
In Stock: 1,191
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 22000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | 21mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 7.57 A @ 120 Hz |
| Ripple Current @ High Frequency | 8.706 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.886" (22.50mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.969" (50.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In - 4 Lead |
ECE-T1HP223EA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 380LX223M050A052 | Cornell Dubilier Electronics (CDE) | CAP ALUM 22000UF 20% 50V SNAP | 100% | View |
| MAL205057223E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 22000UF 40V RADIAL | 85% | View |
| 35USG22000MEFCSN35X40 | Rubycon | CAP ALUM 22000UF 20% 35V SNAP | 81% | View |
| 35USC22000MEFC30X45 | Rubycon | CAP ALUM 22000UF 20% 35V SNAP | 81% | View |
| 25USC22000MEFC30X35 | Rubycon | CAP ALUM 22000UF 20% 25V SNAP | 61% | View |
| MAL216254223E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 22000UF 20% 10V SNAP | 58% | View |
Submit your RFQ for ECE-T1HP223EA and get a quote within 24 hours.
