Panasonic Electronic Components
CAP CER 56PF 3KV SL/GP SMD
ECC-T3F560JG is a Ceramic Capacitors manufactured by Panasonic Electronic Components. CAP CER 56PF 3KV SL/GP SMD. Key specifications: mounting type Surface Mount, MLCC, operating temperature -25°C ~ 105°C, voltage - rated 3000V (3kV), package / case Nonstandard SMD.
In Stock: 7,168
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 56 pF |
| Tolerance | ±5% |
| Voltage - Rated | 3000V (3kV) |
| Temperature Coefficient | SL/GP |
| Operating Temperature | -25°C ~ 105°C |
| Features | High Voltage |
| Ratings | - |
| Applications | General Purpose |
| Failure Rate | - |
| Mounting Type | Surface Mount, MLCC |
| Package / Case | Nonstandard SMD |
| Size / Dimension | 0.280" L x 0.248" W (7.10mm x 6.30mm) |
| Height - Seated (Max) | - |
| Thickness (Max) | 0.110" (2.80mm) |
| Lead Spacing | - |
| Lead Style | - |
ECC-T3F560JG is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 12107A560JAT2A | KYOCERA AVX | CAP CER 56PF 500V NP0 1210 | 56% | View |
| 0603Y0250560GCT | Knowles Syfer | CAP CER 56PF 25V C0G/NP0 0603 | 56% | View |
| 1206Y0630560GAR | Knowles Syfer | CAP CER 56PF 63V C0G/NP0 1206 | 56% | View |
| VJ0805D560GXBAR | Vishay Vitramon | CAP CER 56PF 100V C0G/NP0 0805 | 56% | View |
| 1812J1K00560KAR | Knowles Syfer | CAP CER 56PF 1KV C0G/NP0 1812 | 56% | View |
| 1812J1K00560GFR | Knowles Syfer | CAP CER 56PF 1KV C0G/NP0 1812 | 56% | View |
Submit your RFQ for ECC-T3F560JG and get a quote within 24 hours.
