DC FAN, HIGH PERFORMANCE, IP69K,
OD172SAP-24HBXCIP69K is a DC Brushless Fans (BLDC) manufactured by Orion Fans. DC FAN, HIGH PERFORMANCE, IP69K,. Key specifications: operating temperature -4 ~ 149°F (-20 ~ 65°C), voltage - rated 24VDC, size / dimension Rectangular/Rounded - 172mm L x 152mm H, termination 2 Wire Leads.
In Stock: 126
| Attribute | Value |
|---|---|
| Product Status | Active |
| Voltage - Rated | 24VDC |
| Size / Dimension | Rectangular/Rounded - 172mm L x 152mm H |
| Width | 51.60mm |
| Air Flow | 323.0 CFM (9.04m³/min) |
| Static Pressure | 1.060 in H2O (264.0 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Noise | 63.5dB |
| Power (Watts) | 50.4 W |
| RPM | 4400 RPM |
| Termination | 2 Wire Leads |
| Ingress Protection | IP69K - Dust Tight, Water Resistant, Waterproof |
| Operating Temperature | -4 ~ 149°F (-20 ~ 65°C) |
| Approval Agency | CE, cURus, TUV, UR |
| Weight | 1.3 lbs (600.0 g) |
Submit your RFQ for OD172SAP-24HBXCIP69K and get a quote within 24 hours.
