IC MOTOR DRIVER 6V-15V 36SSOPJ
LV8804V-TLM-H is a PMIC - Motor Drivers, Controllers manufactured by onsemi. IC MOTOR DRIVER 6V-15V 36SSOPJ. Key specifications: mounting type Surface Mount, operating temperature -30°C ~ 95°C (TA), voltage - supply 6V ~ 15V, package / case 36-LSOP (0.220", 5.60mm Width) Exposed Pad.
In Stock: 46,000
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushless DC (BLDC) |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge (3) |
| Interface | PWM |
| Technology | Bi-CMOS |
| Step Resolution | - |
| Applications | Fan Motor Driver |
| Current - Output | 1.2A |
| Voltage - Supply | 6V ~ 15V |
| Voltage - Load | 6V ~ 15V |
| Operating Temperature | -30°C ~ 95°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 36-LSOP (0.220", 5.60mm Width) Exposed Pad |
| Supplier Device Package | 36-SSOPJ |
LV8804V-TLM-H is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LV8805SV-MPB-H | Sanyo | MOTOR DRIVER IC | 100% | View |
| LV8805SV-TLM-H | onsemi | IC MOTOR DRIVER 6V-15V 20SSOP | 100% | View |
| AMIS30523C5231G | onsemi | IC MTRDRV BIPLR 4.75-5.25V 52QFN | 96% | View |
| AMIS30523C5231RG | onsemi | IC MTRDRV BIPLR 4.75-5.25V 52QFN | 96% | View |
| NCV70522MN003G | onsemi | IC MTRDRV BIPLR 4.75-5.25V 32QFP | 96% | View |
| MP6510DM-LF-Z | Monolithic Power Systems Inc. | IC MOTOR DRIVER 4.5V-16V 16TSSOP | 90% | View |
Submit your RFQ for LV8804V-TLM-H and get a quote within 24 hours.
