IC GATE NAND 3CH 3-INP 14SOP
DM74ALS10ASJX is a Logic - Gates and Inverters manufactured by onsemi. IC GATE NAND 3CH 3-INP 14SOP. Key specifications: mounting type Surface Mount, operating temperature 0°C ~ 70°C, voltage - supply 4.5V ~ 5.5V, package / case 14-SOIC (0.209", 5.30mm Width).
In Stock: 1,604
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Logic Type | NAND Gate |
| Number of Circuits | 3 |
| Number of Inputs | 3 |
| Features | - |
| Voltage - Supply | 4.5V ~ 5.5V |
| Current - Quiescent (Max) | - |
| Current - Output High, Low | 400µA, 8mA |
| Logic Level - Low | 0.8V |
| Logic Level - High | 2V |
| Max Propagation Delay @ V, Max CL | 11ns @ 5V, 50pF |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-SOP |
| Package / Case | 14-SOIC (0.209", 5.30mm Width) |
DM74ALS10ASJX is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| SN74ALS10AD | Texas Instruments | IC GATE NAND 3CH 3-INP 14SOIC | 100% | View |
| 5962-86833012A | Texas Instruments | IC GATE NAND 4CH 2-INP 20LCCC | 90% | View |
| SN7400D | Texas Instruments | IC GATE NAND 4CH 2-INP 14SOIC | 83% | View |
| DM74LS132SJ | Fairchild Semiconductor | NAND GATE, LS SERIES TTL | 70% | View |
| SN74ALS133NSR | Texas Instruments | IC GATE NAND 1CH 13-INP 16SO | 68% | View |
| SN74ALS133DE4 | Texas Instruments | IC GATE NAND 1CH 13-INP 16SOIC | 68% | View |
Submit your RFQ for DM74ALS10ASJX and get a quote within 24 hours.
