CM6100
TVS DIODE 3VWM 9.8VC 4WLCSP
CM6100 is a TVS - Diodes manufactured by onsemi. TVS DIODE 3VWM 9.8VC 4WLCSP. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C (TA), package / case 4-UFBGA, WLCSP.
In Stock: 9,600
Product Attributes
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Type | Steering (Rail to Rail) |
| Unidirectional Channels | 2 |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 3V |
| Voltage - Breakdown (Min) | 6V |
| Voltage - Clamping (Max) @ Ipp | 9.8V (Typ) |
| Current - Peak Pulse (10/1000µs) | 1A (8/20µs) |
| Power - Peak Pulse | - |
| Power Line Protection | Yes |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 4-UFBGA, WLCSP |
| Supplier Device Package | 4-WLCSP (0.8x0.8) |
Frequently Asked Questions
CM6100 is a TVS - Diodes manufactured by onsemi. TVS DIODE 3VWM 9.8VC 4WLCSP
The mounting type of CM6100 is Surface Mount.
The operating temperature range of CM6100 is -40°C ~ 85°C (TA).
The package type of CM6100 is 4-UFBGA, WLCSP.
Yes, CM6100 is listed as Obsolete. Consider requesting a quote for alternative parts.
