SWITCH SELECT 3POS DPST 10A 120V
A22NW-3RM-TRA-G102-RC is a Selector Switches manufactured by Omron Automation and Safety. SWITCH SELECT 3POS DPST 10A 120V. Key specifications: mounting type Panel Mount, operating temperature -25°C ~ 55°C, voltage rating - dc 24 V, current rating (amps) 10A (AC), 8A (DC).
In Stock: 10
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Standard |
| Circuit | DPST-NO/NC |
| Number of Positions | 3 |
| Switch Function | On-Off-Off, On-On-Off |
| Current Rating (Amps) | 10A (AC), 8A (DC) |
| Voltage Rating - AC | 120 V |
| Voltage Rating - DC | 24 V |
| Illumination | Illuminated |
| Illumination Type, Color | LED, Red |
| Illumination Voltage (Nominal) | 24 VAC/DC |
| Mounting Type | Panel Mount |
| Termination Style | Screw Terminal |
| Panel Cutout Dimensions | Circular - 22.30mm Dia |
| Ingress Protection | IP66 - Dust Tight, Water Resistant |
| Features | Bezel - Round, Red Knob |
| Operating Temperature | -25°C ~ 55°C |
Submit your RFQ for A22NW-3RM-TRA-G102-RC and get a quote within 24 hours.
