NANO 12POS MALE/FEMALE POLARIZED
A79624-001 is a Rectangular Connectors - Headers, Male Pins manufactured by Omnetics. NANO 12POS MALE/FEMALE POLARIZED. Key specifications: mounting type Through Hole, contact material Beryllium Copper, Copper Alloy, current rating (amps) 1A, termination Solder.
In Stock: 51
| Attribute | Value |
|---|---|
| Product Status | Active |
| Connector Type | Header |
| Contact Type | Female Socket; Male Pin |
| Pitch - Mating | 0.025" (0.64mm) |
| Number of Positions | 12 |
| Number of Rows | 2 |
| Row Spacing - Mating | 0.040" (1.02mm) |
| Number of Positions Loaded | All |
| Style | Board to Cable/Wire |
| Shrouding | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | Push-Pull |
| Contact Length - Mating | 0.060" (1.52mm) |
| Contact Length - Post | 0.100" (2.54mm) |
| Overall Contact Length | - |
| Insulation Height | 0.170" (4.32mm) |
| Contact Shape | Circular |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | - |
| Contact Finish - Post | Gold |
| Contact Material | Beryllium Copper, Copper Alloy |
| Insulation Material | Thermoplastic |
| Features | - |
| Operating Temperature | - |
| Ingress Protection | - |
| Material Flammability Rating | - |
| Insulation Color | - |
| Current Rating (Amps) | 1A |
| Voltage Rating | - |
Submit your RFQ for A79624-001 and get a quote within 24 hours.
