100W SOT227 0.50 OHMS 5%
TGHDXR500JE is a Chassis Mount Resistors manufactured by Ohmite. 100W SOT227 0.50 OHMS 5%. Key specifications: mounting feature Flanges, operating temperature -55°C ~ 155°C, package / case SOT-227-2, size / dimension 1.260" L x 0.748" W (32.00mm x 19.00mm).
In Stock: 8,092
| Attribute | Value |
|---|---|
| Product Status | Active |
| Resistance | 500 mOhms |
| Tolerance | ±5% |
| Power (Watts) | 100W |
| Composition | Thick Film |
| Temperature Coefficient | ±100ppm/°C |
| Operating Temperature | -55°C ~ 155°C |
| Features | Current Sense, Non-Inductive |
| Coating, Housing Type | Epoxy Coated |
| Mounting Feature | Flanges |
| Size / Dimension | 1.260" L x 0.748" W (32.00mm x 19.00mm) |
| Height - Seated (Max) | 0.236" (6.00mm) |
| Lead Style | Wire Leads |
| Package / Case | SOT-227-2 |
| Failure Rate | - |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| TGHDVR500JE | Ohmite | 100W MINI SOT227 0.50 OHMS 5% | 100% | View |
| TGHMVR500JE | Ohmite | 0.5 OHM 300 WATT SOT227 5% TF | 56% | View |
| PF2272-0R5J1 | Riedon | RES CHAS MNT 0.5 OHM 5% 200W | 56% | View |
| TGHLVR500JE | Ohmite | RES CHAS MNT 0.5 OHM 5% 200W | 56% | View |
| TAP2000HCKR50E | Ohmite | 2000 WATT HEAT SINKABLE PLANAR R | 56% | View |
| TGHPVR500KE | Ohmite | SOT-227 600W 0.5 OHM | 56% | View |
