CAP ALUM 33UF 20% 63V RADIAL
UVR1J330MED1TA is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 33UF 20% 63V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 63 V, package / case Radial, Can.
In Stock: 1,777
| Attribute | Value |
|---|---|
| Product Status | Not For New Designs |
| Capacitance | 33 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 140 mA @ 120 Hz |
| Ripple Current @ High Frequency | 280 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.248" Dia (6.30mm) |
| Height - Seated (Max) | 0.492" (12.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
UVR1J330MED1TA is Not For New Designs. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EKYB630ELL330MF11D | United Chemi-Con | CAP ALUM 33UF 20% 63V RADIAL | 95% | View |
| EEU-FC1J330B | Panasonic Electronic Components | CAP ALUM 33UF 20% 63V RADIAL | 94% | View |
| MALREKB00BA233JM0K | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 33UF 20% 63V RADIAL | 94% | View |
| UAQ2G330MHD6 | Nichicon | CAP ALUM 33UF 20% 400V RADIAL | 68% | View |
| NPA33M16 | NTE Electronics, Inc | CAP ALUM 33UF 20% 16V AXIAL | 56% | View |
| ELXZ350ELL330MEB5D | United Chemi-Con | CAP ALUM 33UF 20% 35V RADIAL | 54% | View |
