CAP ALUM 220UF 20% 50V SMD
UUG1H221MNQ1ZD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 220UF 20% 50V SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C, voltage - rated 50 V, package / case Radial, Can - SMD.
In Stock: 3,853
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 220 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 450 mA @ 120 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 0.571" (14.50mm) |
| Surface Mount Land Size | 0.535" L x 0.535" W (13.60mm x 13.60mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
UUG1H221MNQ1ZD is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEE-TC1E221V | Panasonic Electronic Components | CAP ALUM 220UF 20% 25V SMD | 69% | View |
| EEE-FK1E221AV | Panasonic Electronic Components | CAP ALUM 220UF 20% 25V SMD | 67% | View |
| 25TLV220M8X10.5 | Rubycon | CAP ALUM 220UF 20% 25V SMD | 64% | View |
| MAL216099704E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 220UF 20% 80V SMD | 63% | View |
| EEE-TP1E221AP | Panasonic Electronic Components | CAP ALUM 220UF 20% 25V SMD | 61% | View |
| EEE-FP1A221AL | Panasonic Electronic Components | CAP ALUM 220UF 20% 10V SMD | 61% | View |
Submit your RFQ for UUG1H221MNQ1ZD and get a quote within 24 hours.
