CAP ALUM 22UF 20% 450V RADIAL
URU2W220MRD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 22UF 20% 450V RADIAL. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 85°C, voltage - rated 450 V, package / case Radial, Can.
In Stock: 9,114
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 22 µF |
| Tolerance | ±20% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -25°C ~ 85°C |
| Polarization | - |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 160 mA @ 120 Hz |
| Ripple Current @ High Frequency | 256 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Height - Seated (Max) | 0.571" (14.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
URU2W220MRD is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| SEK220M400ST | Cornell Dubilier Electronics (CDE) | CAP ALUM 22UF 20% 400V RADIAL | 92% | View |
| EGXE351ELL220MK25S | United Chemi-Con | CAP ALUM 22UF 20% 350V RADIAL | 88% | View |
| MAL214262296E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 22UF 20% 400V RADIAL | 83% | View |
| EEU-FC1J220B | Panasonic Electronic Components | CAP ALUM 22UF 20% 63V RADIAL | 77% | View |
| EKXJ351ETD220MJ20S | United Chemi-Con | CAP ALUM 22UF 20% 350V RADIAL | 71% | View |
| UCY2H220MHD3TN | Nichicon | CAP ALUM 22UF 20% 500V RADIAL | 65% | View |
