CAP ALUM 68UF 20% 200V RADIAL
URU2D680MRD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 68UF 20% 200V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 200 V, package / case Radial, Can.
In Stock: 3,573
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 68 µF |
| Tolerance | ±20% |
| Voltage - Rated | 200 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | - |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 330 mA @ 120 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Height - Seated (Max) | 0.571" (14.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
URU2D680MRD is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B41858G8686M006 | EPCOS - TDK Electronics | CAPACITOR | 100% | View |
| 200BXW68MEFR12.5X20 | Rubycon | CAP ALUM 68UF 20% 200V RADIAL | 84% | View |
| URS2C680MHD6 | Nichicon | CAP ALUM 68UF 20% 160V RADIAL | 78% | View |
| 686LMU450M2BD | Cornell Dubilier / Illinois Capacitor | CAP ALUM 68UF 20% 450V SNAP | 64% | View |
| 450CXW68MEFR18X25 | Rubycon | CAP ALUM 68UF 20% 450V RADIAL | 56% | View |
| EKXJ421ELL680MM25S | United Chemi-Con | CAP ALUM 68UF 20% 420V RADIAL | 51% | View |
Submit your RFQ for URU2D680MRD and get a quote within 24 hours.
