CAP ALUM 680UF 20% 35V RADIAL
URU1V681MHD1TO is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 680UF 20% 35V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 35 V, package / case Radial, Can.
In Stock: 4,432
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 680 µF |
| Tolerance | ±20% |
| Voltage - Rated | 35 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 720 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.08 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 0.551" (14.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
URU1V681MHD1TO is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B41041B7687M | EPCOS - TDK Electronics | CAP ALUM 680UF 20% RADIAL | 100% | View |
| MAL211826681E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 680UF 20% 25V AXIAL | 84% | View |
| MAL202116681E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 680UF 20% 25V AXIAL | 78% | View |
| NEV680M50FF | NTE Electronics, Inc | CAP ALUM 680UF 20% 50V RADIAL | 77% | View |
| 25ZLH680MEFC10X16 | Rubycon | CAP ALUM 680UF 20% 25V RADIAL | 71% | View |
| 35ZLJ680MCE10X25 | Rubycon | CAP ALUM 680UF 20% 35V RADIAL | 57% | View |
