CAP ALUM 680UF 20% 35V RADIAL
URU1V681MHD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 680UF 20% 35V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 35 V, package / case Radial, Can.
In Stock: 3,157
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 680 µF |
| Tolerance | ±20% |
| Voltage - Rated | 35 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 720 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.08 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 0.551" (14.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
URU1V681MHD is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MALIEYN07BA368N02K | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 680UF 20% SNAP | 100% | View |
| SL687M035HGJRR | NextGen Components | CAP ALUM 680UF 20% 35V 10K HRS | 100% | View |
| UPJ1V681MHD6TN | Nichicon | CAP ALUM 680UF 20% 35V RADIAL | 78% | View |
| 100YXH680MEFC18X35.5 | Rubycon | CAP ALUM 680UF 20% 100V RAD TH | 57% | View |
| 10YXS680MEFC8X11.5 | Rubycon | CAP ALUM 680UF 20% 10V RADIAL | 56% | View |
| LKX2E681MESB40 | Nichicon | CAP ALUM 680UF 20% 250V SNAP | 56% | View |
Submit your RFQ for URU1V681MHD and get a quote within 24 hours.
