CAP ALUM 4.7UF 20% 50V RADIAL
UMT1H4R7MDD1TE is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 4.7UF 20% 50V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 50 V, package / case Radial, Can.
In Stock: 7,188
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 4.7 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 19 mA @ 120 Hz |
| Ripple Current @ High Frequency | 28.5 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.197" Dia (5.00mm) |
| Height - Seated (Max) | 0.236" (6.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
UMT1H4R7MDD1TE is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UEP1J4R7MDD1TD | Nichicon | CAP ALUM 4.7UF 20% 63V RADIAL | 85% | View |
| EKMA350ELL4R7MD07D | United Chemi-Con | CAP ALUM 4.7UF 20% 35V RADIAL | 84% | View |
| SEK3R3M050ST | Cornell Dubilier Electronics (CDE) | CAP ALUM 3.3UF 20% 50V RADIAL | 72% | View |
| UKT1H4R7MDD | Nichicon | CAP ALUM 4.7UF 20% 50V RADIAL | 71% | View |
| 517D475M050JA6AE3 | Vishay Sprague | CAP ALUM 4.7UF 20% 50V RADIAL | 71% | View |
| 100PX4R7MEFCT15X11 | Rubycon | CAP ALUM 4.7UF 20% 100V RADIAL | 52% | View |
Submit your RFQ for UMT1H4R7MDD1TE and get a quote within 24 hours.
