CAP ALUM 47UF 20% 6.3V RADIAL
UMT0J470MDD1TP is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 47UF 20% 6.3V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 6.3 V, package / case Radial, Can.
In Stock: 5,497
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 47 µF |
| Tolerance | ±20% |
| Voltage - Rated | 6.3 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 36 mA @ 120 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | - |
| Lead Spacing | 0.098" (2.50mm) |
| Size / Dimension | 0.197" Dia (5.00mm) |
| Height - Seated (Max) | 0.236" (6.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
UMT0J470MDD1TP is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ECE-A0JKG470 | Panasonic Electronic Components | CAP ALUM 47UF 20% 6.3V RADIAL | 100% | View |
| UMT0J470MDD1TE | Nichicon | CAP ALUM 47UF 20% 6.3V RADIAL | 100% | View |
| MAL212363479 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 47UF 20% 6.3V AXIAL | 85% | View |
| 860080573003 | Würth Elektronik | CAP ALUM 47UF 20% 35V RADIAL | 56% | View |
| 860080674005 | Würth Elektronik | CAP ALUM 47UF 20% 50V RADIAL | 56% | View |
| ELXY630ELL470MJC5S | United Chemi-Con | CAP ALUM 47UF 20% 63V RADIAL | 56% | View |
