CAP ALUM 3.3UF 20% 35V RADIAL
UMF1V3R3MDD1TE is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 3.3UF 20% 35V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 35 V, package / case Radial, Can.
In Stock: 5,222
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 3.3 µF |
| Tolerance | ±20% |
| Voltage - Rated | 35 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 25 mA @ 120 Hz |
| Ripple Current @ High Frequency | 50 mA @ 100 kHz |
| Impedance | 5 Ohms |
| Lead Spacing | 0.059" (1.50mm) |
| Size / Dimension | 0.157" Dia (4.00mm) |
| Height - Seated (Max) | 0.236" (6.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
UMF1V3R3MDD1TE is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL212317338E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 3.3UF 20% 40V AXIAL | 84% | View |
| 860160672004 | Würth Elektronik | CAP ALUM 3.3UF 20% 50V RADIAL | 83% | View |
| UEP1H3R3MDD1TA | Nichicon | CAP ALUM 3.3UF 20% 50V RADIAL | 83% | View |
| UEP2A3R3MED | Nichicon | CAP ALUM 3.3UF 20% 100V RADIAL | 79% | View |
| EEU-FC1H3R3 | Panasonic Electronic Components | CAP ALUM 3.3UF 20% 50V RADIAL | 61% | View |
| 600D335G250DC5 | Vishay Sprague | CAP ALUM 3.3UF 250V AXIAL | 56% | View |
Submit your RFQ for UMF1V3R3MDD1TE and get a quote within 24 hours.
